45mm Ball Bearing Soft Close Runner (Bottom Mount)
Available Lengths
The product is available in 400mm length only, which determines the maximum depth of the drawer you can use them with:
- 400mm (approx. 16 inches)
The longer the closed length, the deeper the drawer and the longer the extended length will be (as they are full extension).
Packaging Details
- Box of 15: This likely refers to a box containing 15 pairs of runners (a total of 30 individual slide members). Runners are typically sold in pairs—one for the left side and one for the right side of a single drawer.
| Attribute | Key | Specification |
| Product Name | IDENTIFIER | Ball Bearing Soft Close Runner |
| Slide Width | DIMENSION | 45mm |
| Load Capacity | RATING | 45kg (99 lbs) |
| Mounting | MECHANISM | Bottom Mount |
| Function | MECHANISM | Soft Close (Integrated dampening mechanism) |
| Available Sizes (Length) | DIMENSIONS | 400mm |
| Unit Packaging | QUANTITY | Box of 15 |
| General Description | DETAIL | A heavy-duty, full-extension drawer slide featuring ball bearings for smooth action and a soft-close mechanism for quiet, safe closing. |
These are full-extension, side-mount drawer slides widely used in cabinetry, furniture, kitchens, offices, and storage applications.
| Category | Key Feature / Specification | Detail & Description |
| Product Type | Ball Bearing Drawer Slide | Utilizes precision steel ball bearings housed in intermediate members for exceptionally smooth and quiet travel. |
| Load Capacity | Heavy-Duty | Rated for 45kg (45-kilogram), making it suitable for larger, deeper, or heavier drawers such as file cabinets and large kitchen pot drawers. |
| Functionality | Soft Close | An integrated damper in the slide automatically slows the drawer before it closes, ensuring a silent and gentle closing action and preventing slamming. |
| Mounting | Bottom Mount | The slide is attached to the bottom of the drawer box and the cabinet opening. It requires a standard 12.7mm (1/2 inch) clearance on each side. |
| Extension | Full Extension | Typically, 40mm ball bearing slides are full extension, allowing the drawer to open completely so you can access everything in the back. |
| Finish | Zinc Plated | Usually coated with a bright or yellow zinc plating for corrosion resistance. |
| Available Lengths | Standard | 400mm only |
